Height | 1640 | Internal Diameter | 500 |
External Diameter | 600 | Insulation | 50 |
Drain 3/4″ female | 250 | Cold Feed 1″ female | 350 |
Solar Coil Outlet 3/4″female | 250 | Solar Coil Feed 3/4″female | 520 |
Solar Coil: Stainless Steel (diameter) | 22 | Boiler Coil Outlet 3/4″female | 800 |
Boiler Coil Feed 3/4″female | 1046 | Boiler Coil: Stainless Steel (diameter) | 22 |
1″Gravity Coil Outlet | none | 1″Gravity Coil Feed | none |
Gravity Coil: Stainless Steel (diameter) | none | 3Kw Immersion 1 | 650 |
3Kw Immersion 2 | none | Temp Sensor Pocket 1 1/2″ female | 540 |
Temp Sensor Pocket 2 1/2″ female | 1315 | Double Stat Temp Sen. Pocket | 740 |
Secondary Return 3/4″female | 1215 | T & P Valve 1/2″ female | 1315 |
Hot Draw Off 1″ female | 1640 | Standard Heat Loss per 24 Hours (kWhr) | 2.1 |
Dedicated Solar Volume (ℓ) | 160 | Dedicated Solar Volume (%) | 53.33 |
EN12897 Solar Heat Exchanger (kW) | 35.86 | Solar Coil (m²) | 1.3 |
EN12897 Boiler Coil Exchanger (kW) | 27.58 | Boiler Coil Surface Area (m²) | 1 |
EN12977 ERP Storage Energy Efficiency Class | A |
