TSOL-MP2250 — 2250W Microinverter

• 2250W nominal continuous AC output
• Up to 4 PV modules / 4 DC inputs
• 4 independent MPPTs for optimized energy harvesting
• 18–60V MPPT voltage range per input
• 60V maximum DC input voltage per input
• Up to 20A maximum input current per input
• Recommended PV module power: 400–700+ W
• Up to 97.2% peak inverter efficiency
• 99.9% nominal MPPT efficiency
• Power factor >0.99 by default
• Low output current THD: <3%
• IP67 protection
• Natural convection cooling — no fan
• Operating temperature: −25°C to +65°C
• Wi-Fi/Bluetooth communication, with RS485 / optional 4G
• Transformerless design
• 12-year standard warranty
• Plug-and-play installation
• Integrated Loss of Mains (LoM) protection
• Designed for high-power 182/210 mm solar modules.
